TECHNICAL DATA
EN / Mass Charger 12/60-2; 12/80-2; 24/50-2; 24/75; 24/100; 3-24/100; 48/25; 48/50 / July 2010 23
Model 24/100-C 3-24/100 48/25 48/50
Article no. 40021006 40031006 40040256 40040506
INPUT
Mains voltage 230V, -10% + 15% 3 x 400 V 230V, -10% + 15% 230V, -10% + 15%
Frequency 50 Hz ± 5 Hz 50 Hz ± 5 Hz 50 Hz ± 5 Hz 50 Hz ± 5 Hz
Inrush current None, the battery charger is equipped with a soft start in accordance with IEC 1003-3
Current 16 A 6.5 A 8 A 16 A
Power factor (Cos phi) 1 0.8 1 1
Efficiency 89% 89% 89% 89%
Input power 3600W 3500W 1800W 3600W
OUTPUT
Nominal voltage 24V DC 24V DC 48 V DC 48 V DC
Charge current 100 A 100 A 25 A 50 A
Outputs 1 x 100 A 1 x 100 A 1x25 A 1x50 A
Charge characteristic three-step plus, fully
automatic
three-step plus, fully
automatic
three-step plus, fully
automatic
three-step plus, fully
automatic
Kind of batteries open and closed lead acid (gel or wet),
Li-ion (settings: section 7.10)
Default charge voltages at
25°C
absorption 28.5 V 28.5 V 57 V 57 V
float 26.5 V 26.5 V 53 V 53 V
Voltage ripple max. 100mV RMS with resistive load @ full power
Short circuit current (1/4 of
max.)
25 A 25 A 6 A 12.5 A
Cable size (within 3 m) 35 mm2 35 mm2 16 mm2 25 mm2
Charger fuse (external) 125 A 125 A 32 A 63 A
ENVIRONMENTAL
Ambient temperature -20 to 40°C @ 100% output power, derated with 2,5% / °C above 40°C
Cooling Forced air, by means of a ventilator with variable speed
Humidity Maximum 95%RV, non condensing
MASTERBUS
MasterBus powering
capability
Yes Yes Yes Yes
MasterBus menu
languages
English, Dutch, German, French, Spanish, Italian
ENCLOSURE TYPE C3 C3 C2 C3
Dimensions (hxwxd) mm See figure 13 See figure 13 See figure 12 See figure 13
Protection degree IP23 IP23 IP23 IP23
Weight 9 kg 10 kg 5 kg 9 kg
* Adjustable, see chapter 5 for settings.
Specifications are subject to change without prior notice.
