SPECIFICATIONS
EN / SunMaster CS15TL/CS20TL / August 2010 27
10.2 OUTLINE DRAWINGS
Figure 43: Outline drawings of the
CS15TL/CS20TL.
All dimensions are in mm (inch).
1055 (41.5)
971 (38.2)
647 (25.4)
242 (9.53)
255 (10.0)
13,3 (0.52)
