ORDERING INFORMATION
28 August 2010 / SunMaster CS15TL/CS20TL / EN
11 ORDERING INFORMATION
Part number Description
131300200 StringMaster CS 2-6 SW Pro, string box for maximum 2x6 strings.
131300250 StringMaster CS 2-6 SW, string box for maximum 2x6 strings.
131300100 Isolation transformer CS-IT20
77040000 MasterBus terminating device
77040020* MasterBus connection cable (UTP patch cable), 0,2m / 0.6ft
77040050* MasterBus connection cable (UTP patch cable), 0,5m / 1.6ft
77040100* MasterBus connection cable (UTP patch cable), 1,0m / 3.3ft
77030100 MasterBus - USB interface (required as interface between your PC and the CS15TL/CS20TL )
77010105 MasterView Easy MkII. (monitoring and control panel for configuration of the power modules with the local
regulations for grid connection).
130394000 QS Data Control 'Basic' – Free software package to monitor your photovoltaic (PV) system using your PC or
notebook. Use of QS PC Link is compulsory.
130391010 QS PC Link, RS485/232 converter (up to 3 CS15TL/CS20TL).
130391020 QS PC Link Industrial, RS485/RS232 converter for the connection of more than 3 CS15TL/CS20TL inverters or
for cable lengths of more than 100 meters.
130391040 QS PC-Link Industrial, RS485/USB converter for the connection of more than 3 CS15TL/CS20TL inverters or
for cable lengths of more than 100 meters.
130396000 QS Data Control 'Premium’ II local – Datalogger to monitor up to 6 CS15TL/CS20TL inverters locally .
130396100 QS Data Control 'Premium’ II remote – Datalogger to monitor up to 6 CS15TL/CS20TL inverters over the
Internet .
130396200 QS Data Control 'Pro’ Analogue – Datalogger to monitor up to 20 CS15TL/CS20TL inverters locally or over the
Internet .
130396210 QS Data Control 'Pro’ ISDN – Datalogger to monitor up to 20 CS15TL/CS20TL inverters locally or over the
Internet .
130396220 QS Data Control 'Pro’ GSM – Datalogger to monitor up to 20 CS15TL/CS20TL inverters locally or over the
Internet .
130396230 QS Data Control 'Pro’ Ethernet – Datalogger to monitor up to 20 CS15TL/CS20TL inverters locally or over the
Internet .
130010905 RS485 modular communication cable, cross wired, 8 pole, 1 meter / 3 ft
130010906 RS485 modular communication cable, cross wired, 8 pole, 5 meter / 16 ft
130010910 RS485 modular communication cable, cross wired, 8 pole, 10 meter / 33 ft
130010915 RS485 modular communication cable, cross wired, 8 pole, 15 meter / 49 ft
120107000 Complete set to assemble RS485 modular communication cables.
Delivery includes: 100 meter modular cable, 100 pcs. modular jacks and crimping tool.
*Other lengths of MasterBus connection cables upon request
See section 6.1 for an overview of parts that are standardly included with the delivery of the CS15TL/CS20TL
Mastervolt offers a wide range of products for both grid connected and independent autonomous electrical installations.
See www.mastervolt.com for an extensive overview of all our products.
