GENERAL INFORMATION
EN / SunMaster CS15TL/CS20TL / August 2010 5
1 GENERAL INFORMATION
1.1 PRODUCT DESCRIPTION
The Sunmaster CS15TL and CS20TL, further referred to
as “CS15TL/CS20TL” or “inverter” are grid connected
solar inverters. This inverter type is used to convert
photovoltaic power and feed this into a three phase grid.
The CS15TL/CS20TL is not suitable for stand-alone use
(i.e. use without public grid).
1.2 USE OF THIS MANUAL
Copyright © 2010 Mastervolt. All rights reserved.
Reproduction, transfer, distribution or storage of part or all
of the contents in this document in any form without the
prior written permission of Mastervolt is prohibited.
This manual serves as a guideline for the safe and
effective use and installation of the CS15TL/CS20TL:
• For the electrician this manual gives directions for the
installation, operation and commissioning.
• For the end-user this manual gives directions for the
operation, maintenance and possible correction of
minor malfunctions of the CS15TL/CS20TL.
• Every person who works with the apparatus should be
familiar with the contents of this manual, and must
carefully follow the instructions contained herein.
• Store the manual in a user accessible place.
1.3 VALIDITY OF THIS MANUAL
This manual is valid for the following models:
Part no Model
131200150 Sunmaster CS15TL
131200200 Sunmaster CS20TL
All the specifications, provisions and instructions contained
in this manual apply solely to the Mastervolt-delivered
standard version of the CS15TL/CS20TL.
1.4 GUARANTEE SPECIFICATIONS
Mastervolt assures the product guarantee of the
CS15TL/CS20TL during five years after your purchase, on
the condition that all instructions and warnings given in this
manual are taken into account during installation and
operation.
Among other things, this means that installation is carried
out by a qualified electrician, that installation and
maintenance are executed according to the stated
instructions and correct working sequence and that no
changes or repairs may have been performed on the
CS15TL/CS20TL other than by Mastervolt.
The warranty is limited to the costs of repair and/or
replacement of the product by Mastervolt only. Costs for
installation labour or shipping of the defective parts are not
covered by this warranty.
For making an appeal on warranty you can contact your
supplier directly, stating your complaint, application, date
of purchase and part number / serial number.
1.5 LIABILITY
Mastervolt accepts no liability for:
• consequential damage due to use of the
CS15TL/CS20TL;
• possible errors in the manuals and the results thereof.
1.6 CHANGES TO THE CS15TL/CS20TL
Changes on the CS15TL/CS20TL may be carried out only
after the written permission of Mastervolt.
1.7 IDENTIFICATION LABEL
Figure 2
The identification label is positioned at the right side of the
CS15TL/CS20TL, see figure 2.
CAUTION!
Never remove the identification label.
Part no : 131200200
Type : MasterSol CS20TL
Input : 250-950Vdc, 1000Vdc Max
MPP 350-800Vdc, 2x30A
Output : 3 phase 400Vac, 50/60Hz, 20kWnom
VDE 0126-1-1
DK 5940
IP65
Serial no: X402-0007
Sunmaster CS20TL
