Mastervolt WHISPER 3,5 User Manual

12 April 2004 / WHISPER 3,5 / USA
INFORMATION
2.5.12 Technical data
GENERAL
Model WHISPER 3,5
RPM 3600
Alternator water cooled, synchronous
Engine Kubota diesel, model OC60 (Japan)
Number of cylinders 1
Displacement 16,84 cubic inches (276 cm3 )
Bore X stroke 2,83 x 2,68 inches (72x68 mm)
Combustion air consumption 15 cfm (0.42 m
3
/min..) at nominal RPM
Continuous power engine/3600 RPM DIN627OB 4,6 kW / 3600 RPM
Cooling system indirect cooling by raw water.
Cooling water pump pto driven Mastervolt self priming impeller pump, type K
Fuel lift pump engine electric pump (12 V DC), additional pump available upon request
Starting battery (optional) 55-90 Ah
Fuel consumption 0,18 - 0,37 gph (0.7-1.4 litre/hour), load dependent
Control Digital Diesel Control including automatic start/stop
ELECTRICAL SPECIFICATIONS
Output voltage 120V 60 Hz alternating current (AC) single phase
Output rating 3.3 KVA = 3.3 kW at powr factor cos phi = 1
Power factor 1
Voltage tolerance ± 5%
Frequency tolerance ± 5%
Alternator brushless, two pole, synchronous
MECHANICAL SPECIFICATIONS
Supply includes generating set, built into tugged GRP sound shield with steel base frame,
mounted on rubber anti vibration mounts
Dimensions wxdxh 19,88 x 15,94 x 19,69 inches(505x400x500 mm)
Colour top white, bottom green
Weight (dry) 214 lbs ( 97 kg) including sound shield
Max. installation angle 25 degrees
Standard supplies Digital Diesel remote panel 45 ft (15 m) cable,
fuel liftpump, fuel filter, lifting eye,
user manual, installation manual
Optional installation kits, mobile (vehicle) version, non earth return, spare part kits
