Mastervolt WHISPER 3,5

14 April 2004 / WHISPER 3,5 / USA
INFORMATION
2.5.14 Lay out control PCB
J20
PUMP
J21
ALT
J1
ALT
J2
REGULATOR
J18 J19 J22
START/STOP
J8 J9
-
J10
-
J11
J12
- -
J13
- -
J14 J16
-
J15 J17
-
WCH/0
--
TA ILOR MADE ENERGY
ALT-L
J3
J4 J6
+
J5 J7
+
MASTERVOLT
+
+
10A 3A
F3
10A
ALT
hold
ct-2
ct-1
ct-1
ct-2
gnd
tem
str.
exh
oil
reg
alt.
fuel
heat start fuel fail
st
gl
+
pull
AC-1 AC-2
LOCAL CONTROL PANEL
BATTERY
RED 16
12VDC
BATTERY
SWITCH
RED 2,5 (13)
RED 6 (1)
BLACK 16
GROUND TO
BLACK 2,5 (2)
TO GENERATOR AC OUTPUT
OIL TEMP.
SWITCH
EXHAUST TEMP.
SWITCH
OIL PRESS.
SWITCH
FUEL
VALV E
SOLENOID
STOP
GLOW (PREHEAT)
PLUGS
FUEL LIFT
PUMP
MOTOR
STARTER
CURRENT MEASURING
TRANSFORMER
BLUE 1 (7)
BLUE/GREEN 1 (8)
BLUE/BLACK 1 (7) J10
BLACK 1,5 (12) J8
BLUE/PINK 1 (8) J12
PURPLE 1 (6)
PURPLE/BLACK 1 (6) J14
BLACK 1.5 (15) J16
BROWN 1,5 (5)
GREY 1,5 (5)
BATTERY CHARGER
BLACK (11)
WINDING GENERATOR
RED (11)
YELLOW 2,5 (4)
GREEN 1,5 (9)
PINK 2,5 (20)
BROWN 4 (3)
ORANGE 1,5 (19)
RED/GREEN 1 (16)
RED 1,5 (14)
_
+
RED 1,5 (10)
RED 1,5 (10)
BROWN (33)
BLUE (33)
AC-1
TO REMOTE CONTROL PANEL
SOLENOID
ENGINE BLOCK
(OPTIONAL)
(OPTIONAL)
Fig. 7: Lay out control PCB.
