Mastervolt Whisper 6 Installation Manual

INSTALLATION
EN/ Whisper 6 / 10 - 3000RPM for mobile applications / August 2009 / Copyright © 2009 Mastervolt / Août 2009 11
A
1
3
2
5
4
Figure 9: Fuel supply (fuel tank is below the generating set)
1 Fuel return
2 Fuel supply
3 Prefilter / Water separator (optional)
4 Extra fuel lift pump (optional)
5 Fuel tank
Figure 10: Fuel line assembly with vertical mounted pump and fuel lift pump mounted in an angle

Mastervolt Whisper 6 Specifications

General

Brand	Mastervolt
Model	Whisper 6
Category	Inverter
Language	English
