INSTALLATION SPECIFICATIONS
EN/ Whisper 6 / 10 - 3000RPM for mobile applications / August 2009 / Copyright © 2009 Mastervolt / Août 2009 23
3.3 TECHNICAL DATA
WHISPER 6 AND 10
Model Whisper 6 Whisper 10
Dimensions (l x w x h) 69.0 x 52.5 x 58.0 cm 80.5 x 52.5 x 58.0 cm
Weight including sound shield 200 kg (440Lbs) 240kg (530Lbs)
Max. operation angle 25° 25°
Remote panel 15 m cable Digital Diesel Control System
Battery capacity min. 12V / 60Ah 12V / 60Ah
Fuel consumption 1-2.5 litre/hour, load dependent 1-4 litre/hour, load dependent
Combustion air consumption 0.95 m3/min. 1.43 m3/min.
Model fuel pump Electrical driven 12V Electrical driven 12V
Max lift fuel pump 1m 1m
Cooling Radiator cooling Radiator cooling
Cooling pump Mastervolt self priming raw water impeller pump, PTO driven
Model cooling pump M M
Alternator synchronous brushless, maintenance free, water cooled
Voltage regulation capacitor capacitor
Output power at 50Hz, power factor cos phi = 1 5 kW* 9 kW*
Battery charger (alternator including regulator): 40 Amps 40 Amps
* Note that this value must be reduced by the power to drive the cooling fans of the radiators.
