DIAGRAMS & DRAWINGS
32 Copyright © 2009 Mastervolt / August 2009 / Whisper 6 / 10 - 3000RPM for mobile applications / EN
4.4 WIRING COLOURS
Cable code number colour cross section
battery > starter motor red 25 mm2
starter motor > DDC 1 red 6 mm2
starter motor > LCP 13 red 2,5 mm2
battery > ground black 25 mm2
ground > LCP ground (GND) 2 black 4 mm2
DDC > glow plugs 3 brown 4 mm2
DDC > starter solenoid 4 yellow 2,5 mm2
LCP > fuel lift pump + 5 brown 1,5 mm2
LCP > fuel lift pump - 15 black 1,5 mm2
DDC > LCD 5 grey 1,5 mm2
DDC > oil pressure switch 6 purple 1 mm2
LCP > oil pressure switch 6 purple/black 1 mm2
DDC > water temperature switch 7 blue 1 mm2
LCP >water temperature switch 7 blue/black 1 mm2
DDC > exhaust temperature switch 8 blue/green 1 mm2
LCP > exhaust temperature switch 8 blue/rose 1 mm2
DDC > fuel solenoid (hold) 9 green 1,5 mm2
DDC > fuel solenoid (pull) 20 pink 1,5 mm2
DDC > fuel solenoid (com.) 17 black 1,5 mm2
B+ terminal alternator > starter motor 21 red 6 mm2
DDC >R terminal alternator 18 wit 1,5 mm2
DDC > L terminal alternator 19 orange 1,5 mm2
DDC > current measuring transformer 11 black 1 mm2
DDC >current measuring transformer 11 red 1 mm2
DDC > LCP 12 black 1,5 mm2
DDC > LCP 14 red 1,5 mm2
DDC > LCP 16 red/green 1,5 mm2
DDC > generator AC output 33 brown 1 mm2
DDC > generator AC output 33 blue 1 mm2
