INSTALLATION SPECIFICATIONS
26 Copyright © 2009 Mastervolt / August 2009 / Whisper 6 / 10 - 3000RPM for mobile applications / EN
DRY EXHAUST KIT 1½”
no qty article no description
61 1 50220043 Exhaust hose SS 500mm fem./male 1½”
62 1 50220042 Insul. blanket 35x60 exhaust hose 1½’
63 1 50230523 Absorbtion muffler steel 1½”
64 1 50230524 Ressonance muffler steel 1½”
65 1 50230525 Insul. blanket 80x75 muffler SDHC 1½”
66 2 50221403 Pipe nipple 1½”x300mm galvanised
67 2 50221423 Parallel male coupling 1½” galvanised
68 2 50221413 Straigt coupling f/f 1½” galvanised
69 3 50221663 U-clamp 48 mm M10
70 3 50221664 Bracket U-clamp 25cm M10/48mm passivated
71 6 50211406 Washer SP M10
72 6 50211447 Washer spring SP M10
73 6 50211466 Nut hexogonal SP M10
75 1 50221473 Elbow 90 degr m/f gavalvanised 1½”
TOTAL 50201875 DRY EXHAUST KIT 1½”
RADIATOR COOLING KIT ALTERNATOR 230VAC
no qty article no description
31 1 50230304 Radiator cooler AP 300/2 E 230VAC
32 2 50221103 Straight reducer m/f 1”-3/4”
33 1 50221063 Male nipple 3/4”
34 1 50221043 TEE fittings 3/4”
35 3 50221004 Male hose connection 3/4x20
38 1 50212405 Temperature switch 35-45 degr
39 4 50201121 Vibration mounting 30x25
40 4 50211152 Bolt hexagonal ZP M8x16
41 8 50211465 Nut hexogonal SP M8
42 8 50211405 Washer SP M8
43 8 50211445 Washer spring SP M8
44 8 50220011 Hose vacum SAE100R4 (3/4”) 19x31,5mm
45 6 50221502 Hose clamp stainless19-29
46 8 50221599 Hose support 35x15 mm galvanised
47 1 50230529 Bracket expansion tank for 50230531
47 1 50230531 Expansion tank 20 mm
47 1 50230532 Cap tank 0502 30531
TOTAL 50201878 RADIATOR COOLING KIT ALTERNATOR 230VAC
RADIATOR COOLING KIT ALTERNATOR 12VDC
Same as article no. 50201878, except:
no qty article no description
31 1 50230302 Radiator cooler AP 300/2 E 12VDC
TOTAL 50201872 Radiator cooling kit alternator 12VDC
RADIATOR COOLING KIT ALTERNATOR 24VDC
Same as article no. 50201878, except:
no qty article no description
31 1 50230303 Radiator cooler AP 300/2 E 24VDC
TOTAL 50201868 Radiator cooling kit alternator 24VDC
