INSTALLATION SPECIFICATIONS
28 Copyright © 2009 Mastervolt / August 2009 / Whisper 6 / 10 - 3000RPM for mobile applications / EN
RADIATOR COOLING KIT ENGINE 230VAC
no qtt article no description
1 1 50230304 Radiator cooler AP 300/2 E 230VAC
2 2 50221502 Hose clamp stainless19-29
3 1 50221064 “Male nipple 1”
4 1 50221044 “TEE fitting 1”
5 2 50221010 Male hose connection 1x25
6 1 50221103 “Straight reducer m/f 1”-3/4”
7 1 50221004 Male hose connection 3/4x20
8 1 50212409 Temperature switch 87-82 degr
9 4 50201121 Vibration mounting 30x25
10 4 50211152 Bolt hexagonal ZP M8x16
11 4 50211465 Nut hexogonal SP M8
12 8 50211405 Washer SP M8
13 8 50211445 Washer spring SP M8
14 6 50220012 “Hose vacum SAE100R4 (1”) 25,4x38mm”
15 4 50221503 Hose clamp stainless 26-38
16 8 50221599 Hose support stainless 35x12 mm
17 1 50230529 Bracket expansion tank for 50230531
17 1 50230531 Expansion tank 20 mm
17 1 50230532 Cap tank 0502 30531
18 1.5 50220011 “Hose vacum SAE100R4 (3/4”) 19x31,5mm
21 1 50221532 Hose clamp stainless mini 9-11
TOTAL 50201879 Radiator cooling kit engine 230VAC
RADIATOR COOLING KIT ENGINE 12VDC
Same as article no. 50201879, except:
no qtt article no description
31 1 50230302 Radiator cooler AP 300/2 E 12VDC
TOTAL 50201871 Radiator cooling kit engine 12VDC
RADIATOR COOLING KIT ENGINE 12VDC
Same as article no. 50201879, except:
no qtt article no description
31 1 50230303 Radiator cooler AP 300/2 E 24VDC
TOTAL 50201880 Radiator cooling kit engine 24VDC
