Using the Scan Tool
VIEWING OEM ENHANCED DTCs (Ford/Mazda only)
13
- Contact Technical Support for assistance.
2. Refer to DISPLAY FUNCTIONS on
page 4 for a description of LCD display
elements.
If the definition for the currently
displayed code is not available,
an advisory message shows.
I/M MONITOR STATUS icons
are not displayed when
viewing enhanced DTCs.
In the case of long code definitions, a small arrow is shown
in the upper/lower right-hand corner of the code display
area to indicate the presence of additional information.
The Scan Tool will display a code only if codes are present in the
vehicle’s computer memory. If no codes are present, a “No OEM
Enhanced DTC’s are presently stored in the vehicle’s computer” is
displayed. Press SYSTEM MENU
to return to the System Menu.
3. If more than one code was retrieved press DTC/FF, as necessary,
to display additional codes one at a time.
Whenever the Scroll function is used to view additional codes,
the Scan Tool’s communication link with the vehicle’s computer
disconnects. To re-establish communication, press POWER/
LINK
again.
4. When the last retrieved DTC has been displayed and DTC/FF is
pressed, the Scan Tool returns to the “Priority” Code.
To view additional enhanced DTCs, repeat steps 1 through 4,
above.
To exit the enhanced mode, press SYSTEM MENU to return
to the System Menu. Select Global OBD, then press ENTER
to return to the Global OBD2 mode.
VIEWING OEM ENHANCED DTCs (Ford/Mazda only)
Mazda Enhanced DTCs are available for Mazda-branded
Ford vehicles only.
When Ford OEM Enhanced is chosen from
the System Menu, the Ford Enhanced
menu displays. You may view DTCs for
either the “Continuous Memory Test”,
“KOEO (Key On Engine Off) Test” or
“KOER (Key On Engine Running) Test.”
1. Select the desired option, then press
ENTER
.
If KOER is selected, an advisory message shows.
Vacuum reservoir control circuit
open
P1250(1/2) Engine
Chrysler OEM Enhanced
Press any Hotkey
To Next Page
