Matrix 7xe User Manual

51
10.1 VA INSTALLATION - CONTINUED
CHAPTER 10: CONSOLE SPECIFICATIONS AND ASSEMBLY GUIDE
1. Remove the console back cover.
2. Push the memory card socket to the right side and the socket will be released (Figure A).
3.
Put the VA memory card in the socket (Figure B).
4.
Push the memory card socket to the left side to secure the memory card (Figure C).
FIGURE C
FIG
URE BFIGURE A
