CHAPTER 10: CONSOLE SPECIFICATIONS AND ASSEMBLY GUIDE
1. T7XE / T7XI RFID INSTALLATION
MAIN COMPONENT LIST OF RFID SET (PART NUMBER #1000375135)
FIGURE
A
Item
Part number
Description
Qty
1 1000355790 Reader;;;GAT-RM310 3.0;V3.1.1.0/V1.2;;EP 1
2 1000355791 Antenna board;;;GAT-MAXI LA 3.0;;;EP614C; 1
3 1000354646 Signal connected wire;;;;;;;850(IPEX,MHF 1
4 1000309516 Tape;;;40x10x0.2;;EP614 4
5 004350-AB SCREW;BH;M3X0.5PX6L;;PH;;;;BP 2
6 1000356734 Fixing Bracket;;;PA746;BL/Black C;;TM521 1
7 008864-A Screw;Round

Head;Φ2.9x1.06Px7L;Hi/Lo

Thr 3
10.2 RFID INSTALLATION
