Matrix C3X-02 User Manual

51
9.3 CONSOLE KEYPAD / OVERLAY REPLACEMENT - CONTINUED
CHAPTER 9: PARTS REPLACEMENT GUIDE
10) Carefully line up the new overlay to the outline in the console faceplate. Once it is in place, press down on the overlay so that the adhesive
on the overlay bonds to the keypad (Figure S & T).
11) Reverse Steps 1-3 to re-assemble the console.
12) Test the unit for function as outlined in Section 9.3.
FIGURE S
FIGURE T
