Matrix E5x-02 User Manual

53
3) Remove the 2 screws on each side holding on the rear end cap and remove it (Figure E & F).
4) Remove the middle plastic cover from between the pedals by pulling it towards the rear of the unit (Figure G).
FIGURE E FIGURE F
FIGURE G
8.20 ROLLER TRACK REPLACEMENT - CONTINUED
CHAPTER 8: PART REPLACEMENT GUIDE
