Matrix ETERNITY GE - ETERNITY ME E&M8 - Amphenol Connector

102 Matrix ETERNITY Quick Start
ETERNITY ME E&M8 - Amphenol Connector
E&M08 CARD
(Lower MDF Connector)
E&M08 CARD
(Upper MDF Connector)
Port Color Port Color
E&M01-M, SB Blue-White E&M05-M, SB Blue-White
E&M01-E, SG Orange-White E&M05-E, SG Orange-White
E&M01-SP(RxA), SP(RxB) Green-White E&M05-SP(RxA), SP(RxB) Green-White
E&M01-SP(A), SP(B) Brown-White E&M05-SP(A), SP(B) Brown-White
E&M01-02 CCS Grey-White E&M05-06 CCS Grey-White
E&M02-M, SB Blue-Red E&M06-M, SB Blue-Red
E&M02-E, SG Orange-Red E&M06-E, SG Orange-Red
E&M02-SP(RxA), SP(RxB) Green-Red E&M06-SP(RxA), SP(RxB) Green-Red
E&M02-SP(A), SP(B) Brown-Red E&M06-SP(A), SP(B) Brown-Red
E&M03-M, SB Grey-Red E&M07-M, SB Grey-Red
E&M03-E, SG Blue-Black E&M07-E, SG Blue-Black
E&M03-SP(RxA), SP(RxB) Orange-Black E&M07-SP(RxA), SP(RxB) Orange-Black
E&M03-04 CCS Green-Black E&M07-08 CCS Green-Black
E&M04-M, SB Brown-Black E&M08-M, SB Brown-Black
E&M04-E, SG Grey-Black E&M08-E, SG Grey-Black
E&M04-SP(RxA), SP(RxB) Blue-Yellow E&M08-SP(RxA), SP(RxB) Blue-Yellow
E&M04-SP(A), SP(B) Orange-Yellow E&M08-SP(A), SP(B) Orange-Yellow
