Matrix ETERNITY GE User Manual

Matrix ETERNITY Quick Start 43
Signaling Type: T1-RBS or T1-PRI
LED1/LED3 Pattern:
LED2/LED4 Pattern:
2. Port Maintenance Mode
LED1/LED3 Pattern:
LED2/LED4 Pattern:
AIS16 Alarm RED 100ms ON-100 ms OFF
RAI Alarm RED 500ms ON-500 ms OFF
AIS or LOS Alarm RED Continuous ON
Port Status Color Cadence
No Alarm GREEN Continuous ON
TFA Alarm or MFA Alarm RED 500ms ON-500 ms OFF
AIS Alarm RED 100ms ON-100 ms OFF
LOS Alarm RED Continuous ON
Port Status Color Cadence
Layer 1 established successfully GREEN Continuous ON
RAI or LOS Alarm RED Continuous ON
Port Status Color Cadence
Maintenance Mode RED - GREEN 500 ms RED-500 ms GREEN
Port Status Color Cadence
Near end loop back wait before activate RED 100ms ON-100 ms OFF
Near end loop active RED Continuous ON
Near end loop back wait before deactivate RED 500ms ON-500 ms OFF
Far end loop back wait after activate GREEN 100ms ON-100 ms OFF
Port Status Color Cadence

Matrix ETERNITY GE Specifications

General

Brand	Matrix
Model	ETERNITY GE
Category	PBX
Language	English
