Matrix G7-S23 - User Frame

16
STEP 3 | CABLE TO SWINGARM ASSEMBLY INSTRUCTIONS & NOTES
ID DESCRIPTION QUANITY
20 M6 Nylock Nut 1
21 User Frame Cable (Pre-assembled to CAM) 1
22 M6 Shoulder Bolt 1
ASSEMBLY
PART 2: CAM/CABLE ASSEMBLY
20
21
22
CAM must be oriented as shown
Torqueto16N-m/142in-lbs.
