Matrix G7-S23 - Parts List

8
Parts List
ID
DESCRIPTION
QTY
1 M10 Nylock Nut 6
2 Weight Stack 1
3 M10 Flat Washer 15
4 M10 X 75L Socket Head Cap Screw 4
5 Upper Connecting Tube 1
6 Lower Connecting Tube 1
7 M10 X 30L Socket Head Cap Screw 8
8 M10 Saddle Washer 4
9 User Frame 1
10 M10 X 45L Socket Head Cap Screw 1
11 Pulley 1
12 Weight Stack Cable 1
13 M10 X 55L Socket Head Cap Screw 4
14 Pivot Block Assembly 1
15 CAM 1
16 Large Pivot Cap 1
17 M10 X 105L Socket Head Cap Screw 2
18 Swingarm 1
19 Medium Pivot Cap 9
20 M6 Nylock Nut 1
21 User Frame Cable (Pre-assembled on CAM) 1
22 M6 Shoulder Bolt 1
23 M8 X 25L Socket Head Cap Screw 8
24 Seat Link 4
25 Axle 4
26 Spring 2
27 Seat 1
28 Tie Rod 2
29 M6 Flat Washer 4
30 M6 X 12L Socket Head Cap Screw 4
31 Wave (Spring) Washer 2
32 Left Arm 1
33 Snap Ring 2
34 Small Pivot Cap 2
35 M10 X 15L Socket Head Cap Screw 2
36 Right Arm 1
37 M8 X 20L Socket Head Cap Screw 4
