Matrix G7-S23 - Part 6 Plastics Assembly; Rear Shroud

26
STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES
PART 6: PLASTICS ASSEMBLY
ID DESCRIPTION QUANITY
45 Rear Shroud 1
46 Left Front Shroud 1
47 Right Front Shroud 1
ASSEMBLY
Install the weight stack shrouds as shown.
45
47
46
