Matrix G7-S23 - Part 5 Pad Assembly; Head Rest Assembly

24
STEP 1 | BACK PAD ASSEMBLY INSTRUCTIONS & NOTES
ID DESCRIPTION QUANITY
40 Head Rest Assembly 1
41 M10 X 75L BHC 4
42 Back Pad Assembly 1
ASSEMBLY
PART 5: PAD ASSEMBLY
42
41
40
41
Install the pad as shown.
Tightento27N-m/20ft-lbs.
