10.7 NETPULSE & AM SETTING UP SOP
10.7.2 Setting up Wired and Wireless Connections in a Facility
Introduction: Each facility has two options for the network setup on their Matrix Fitness 7xi product:
Option 1: A wired connecting solution
The media Gateway is connected to a local internet source, and Ethernet cabling is run to each machine individually, using a switch to source all
of the connections.
Wired Installation Steps:
1. Prepare site for local server and internet connection
a. Find a secure location (like an AV closet or a server room) for the gateway and related network equipment.
b. Make sure the location has power and internet access, as well as a rack or 19” shelf for the gateway.
c. Contract an ISP (Internet Service Provider) to bring internet connectivity to the closet.
i. The minimum bandwidth is 3Mbps down.
ii. Recommended is a bandwidth of 1Mbps down for every 4 Consoles.
CHAPTER 10: BIKE SPECIFICATIONS AND ASSEMBLY GUIDE
