Matrix S-Drive User Manual

13
5.5 rUnninG belT rePlacemenT
1)RemovethesiderailasoutlinedinSection5.2.
2)RemovetherearrollerasoutlinedinSection5.3.
3)RemovetherunningdeckasoutlinedinSection5.4
4)Removethefrontrollerrightsidetwoscrews(FigureA).
5)Oncetherearrollersanddeckareremoved,therunningbeltcanbeliftedupfromfrontrollerrightside(FigureB).
6)ReverseStep1-5toinstallanewrunningbelt.
7)TensiontherunningbeltasoutlinedinSection2.3.
cHaPTer 5: ParTS rePlacemenT GUiDe
fiGUre a
fiGUre b

Matrix S-Drive Specifications

General

Transport Wheels	Yes
Running Surface	20" x 60"
Frame	Steel
Console	LCD
Footprint	191 x 85 cm / 75" x 33.5"
Programs	Manual
Stride Length	Adjustable
