Matrix SATATYA Devices Manual 89
Time: Set the Time by clicking on the up-down scroll button.
Set: Click on the Set button to save the date and Time settings.
Enable the Auto Synchronize with NTP Server checkbox to allow the synchronization between device and
server.
Preferred NTP server: You can specify the IP address or host name of the preferred NTP server to be used to
update and synchronize System’s Real Time Clock periodically at defined time interval. For eg: the server can be
Wisconsin, Windows or NIST.
Update: The Update Interval field specifies the time period in hours between successive time synchronizations.
The options available are:
Every 6 Hours
Every 12 Hours
Every 24 Hours
Note that the date and time of cameras added through ONVIF in the device will be same as set in the
Device Date and Time page.
Language: Select the required Language from the drop-down list which is to be made default for the Local as well
as Device Client.
•The other Languages except English must be configured first by Admin group users at the Device client
to make them available in Language drop-down list for selection.
•The updated language will be reflected in the Device Client or vise-versa after next login.
•The Language feature is available only for SATATYA NVRX variants.
Network
Configure the Network parameters for LAN 1 and LAN 2 of the device as shown below.
LAN 1
