8.7 01A8 / 01AD / 02B6 / 02B7 / 02B8 ERROR TROUBLESHOOTING
ERROR MESSAGE 01A8 / 01AD / 02B6 / 02B7 / 02B8
1) cause:
a. 01A8 - Main motor over current of 7 Amps.
b. 01AD - Motor over temperature.
c. 02B6 - Speed up is over current.
d. 02B7 - Speed down is over current.
e. 02B8 - Running status over current.
2) sOLuTION:
a. See Section 3.6 for checking the status of the running deck and belt. Replace as needed.
b. Replace the MCB.
8.8 01AB ERROR TROUBLESHOOTING
ERROR MESSAGE 01AB
1) cause:
a. Inverter error.
2) sOLuTION:
a. When the display is showing an 01AB error, the MCB Fault LED should be lit (Figure A).
b. If the MCB Fault LED is not lit, replace the console.
c. If the MCB Fault LED is lit, replace the MCB.
FIGURE A
