33
1. If you have status lights on the TV, but the On / Off button gives no response, disconnect and then re-connect the power to the treadmill from
the wall. Attempt to turn on the TV again using the On / Off button.
2. If the TV does not power on check the TV keypad connection at the console (Figure A).
3. Also check the connection of the TV controller wire at the TV (Figure B) and the console (Figure C).
4. If the TV does not power on with the TV keypad, attempt to power on the TV using the small handheld remote that came with the TV (Figure D)
(Used for changing menu and other settings). If the TV will function with the handheld remote, replace the TV keypad. If the TV will not function
with handheld remote it is likely an issue with the TV itself, contact Matrix Customer Technical Support.
8.19 ENTERTAINMENT TROUBLESHOOTING - CONTROLLER ISSUES
FIGURE A FIGURE B
FIGURE DFIGURE C
CHAPTER 8: TROUBLESHOOTING
