Matrix U3X-05 User Manual

32
9.2 CUP HOLDER REPLACEMENT
CHAPTER 9: PART REPLACEMENT GUIDE
1) Remove the 4 screws holding the cup holder to the console mast (Figure A).
2) Remove the cup holder (Figure B).
3) Reverse Steps 1-2 to install a new cup holder.
FIGURE A
FIGURE B
