Matrix U3X-05 User Manual

49
9.18 FRONT STABILIZER REPLACEMENT
1) Remove the 4 screws holding the rear stabilizer to the frame (Figures A & B). .
2) Remove the front stabilizer (Figure C).
3) Reverse Steps 1-2 to install new front side covers.
FIGURE A FIGURE B
FIGURE C
CHAPTER 9: PART REPLACEMENT GUIDE

Matrix U3X-05 Specifications

General

Brand	Matrix
Model	U3X-05
Category	Exercise Bike
Language	English
