Matrix W1X ROWER

29
6.15 HANDLEBAR BRACKET REPLACEMENT
CHAPTER 6: PART REPLACEMENT GUIDE
FIGURE A
FIGURE B
1) Remove the 2 screws holding the handlebar bracket to the frame (Figure A).
2) Remove the handlebar bracket (Figure B).
3) Reverse Steps 1-2 to install a new handlebar bracket.
