Matrox Maevex Series – User Guide 13
Maevex 6150 encoder (Back)
12V DC power
LAN1
(network)
HDMI Out
(monitor)
RS232
(RS232 control
device)
HDMI In
(source)
USB 3.0
(external
storage)
Line In
(source)
DisplayPort
(console display)
LAN2
(network)
