44 Matrox Maevex Series – User Guide
External power supply
Environmental
6150 encoder 5150 encoder 5150 decoder
Input AC voltage range 100V to 240V AC 100V to 240V AC 100V to 240V AC
Input frequency 50 to 60 Hz 50 to 60 Hz 50 to 60 Hz
Input connector IEC 60320-C13 IEC 60320-C8 IEC 60320-C8
Output voltage +12V DC, 5A +5V DC, 3A +5V DC, 3A
Output connector
DIN 4 male (4-pin)
with lock
DIN 4 male (4-pin)
with lock
DIN 4 male (4-pin)
with lock
Maximum power 60 W 15 W 15 W
Temperature, operational 0 to 45 ºC (32 to 113 ºF)
Temperature, non-operational
storage and transportation
-40 to 70 ºC (-40 to 158 ºF)
Humidity, operational (indoor) 20% to 80% (non-condensing)
Humidity, non-operational storage
and transportation
5% to 95% (non-condensing)
Atmospheric pressure, operational
650hPa (3,580 meters / 11,745 feet)
to 1013hPa (0 meters / 0 feet)
Atmospheric pressure,
non-operational and transportation
192hPa (12,000 meters / 39,370 feet)
to 1020hPa (-50 meters / -164 feet)
