12 Matrox Maevex Series – User Guide
Connecting your Maevex 6150 encoder
Connection overview
Maevex 6150 encoder (Front)
Note: Don’t change input connections while your Maevex device is turned on. If
connections are changed while your Maevex device is turned on, your video sources will be
lost.
LCD buttons
USB 2.0
Microphone
Headphone
Programmable
buttons
