Matrox Maevex Series – User Guide 47
Maevex devices
The following are the requirements for a network firewall present on a network with a Maevex
environment.
Accessing your Windows Firewall settings
To access your Windows Firewall settings:
Windows 10/8.1/7 –
1 Windows 10 – Click Start Æ Settings Æ Network & Internet Æ Ethernet Æ Windows
Firewall
.
Windows 8.1 – From the Start screen, go to All Apps Æ Windows System Æ Control
Panel
Æ Network and Internet * Æ Network and Sharing Center *. (* Depending on your
configuration, these steps may be unnecessary.)
Network Port Type Inbound Outbound Functionality
20,21 TCP 9 — FTP: File upload
22
*
* Minimum requirements.
TCP 99SSH: Firmware update
69 UDP — 9 DHCP: DHCP client
123 UDP 99NTP: Network Time Protocol
161 UDP 99
SNMP: Network management (public
community string)
443
*
TCP 9 —
HTTPS: PowerStream Plus
commands, and authentication and
firmware update
1900
*
UDP 99
UPnP: Microsoft SSDP for discovery of
UPnP devices
Ephemeral
*
UDP 99
RTP/RTCP: Audio and video streams
and control
8554 (Maevex
5150), 3049
(Maevex 6100)
*
TCP 99RTSP: Streaming (configurable)
12000
†
† Fixed value when using the Relayed serial over IP feature in PowerStream Plus. User defined when using the Direct
serial over IP
feature in PowerStream Plus.
TCP 99RS232: RS232 virtualization
‡
‡ Maevex 5150 encoder and 5150 decoder only.
Note: You may need administrator rights to modify your Windows Firewall settings. For
more information, see Windows documentation or contact your system administrator.
