Matrox Maevex Series – User Guide 39
Supported resolutions
(DisplayPort video output for
console display)
Up to 2560 × 1600 @ 60 Hz
Multi-encode/
Multi-stream/
Record
§
2× 3840 × 2160 @ 60 Hz, 4× 3840 × 2160 @ 30 Hz,
8× 1920 × 1080 @ 60 Hz, 16× 1280 × 720 @ 60 Hz,
or numerous SD IP channels
Maximum bit rate
(per video stream)
120 Mbps
Maximum combined bit rates
(all video streams and recordings)
¶
800 Mbps
Rate control
Constant bit rate (CBR), Variable bit rate (VBR),
Constrained VBR, Configurable group of pictures (GOP)
Recording MP4 file format
Recording location NAS device, external USB storage device
Power requirements
+12V to 28V DC, maximum 5 A
(5 A fuse for overcurrent protection)
Power connector DIN 4 female (4-pin)
Power consumption
**
Maximum: 45W
Typical: 37.2 W
Dimensions
21.7 cm × 18.9 cm × 4.3 cm /
8.53 in × 7.45 in × 1.68 in
Certifications Class A: ACMA, CE, FCC, ICES, VCCI, Korea
* When using a display resolution equal to or higher than 1280×720p60, we recommend you use certified high-speed HDMI
cables.
† Unless specified, modes are p60 (progressive 60 Hz).
‡ In 4:2:0 only.
§ Color sampling and color depth limitations may apply. For more information, see “Notes and limitations”, page 45.
¶ Depending on network speed and conditions.
** Maximum: Measured cfg is 4 × 3840 × 2160p30, 4:2:0 or equivalent, excluding power drawn by external USB devices.
Typical: Measured cfg is 4 × 1920 × 1080p60, 4:2:0 or equivalent, excluding power drawn by external USB devices.
Maevex 6150 encoder
