Operation
-12- Maverick MK2 Spot User Manual Rev. 4
Operating Settings Configuration
Home Screen
The Maverick MK2 Spot has a home screen that shows the protocol mode, the IP address or DMX
address, the DMX personality, and the current product temperature.
To see the home screen, press
<MENU> repeatedly until it appears on the display.
Start Address
To set the starting address, set the Control Mode and then follow the instructions below:
Press <MENU> repeatedly until the Home Screen shows on the display. Press <ENTER>. 1.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Start Address, or touch the display 2.
where it says Start Address.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Enter the starting address (001–512) with one of the following methods: 4.
• Type the address number using the number pad that shows on the touchscreen display.
or
• Using the buttons (or the button icons on the sides of the display),
Use <LEFT> or <RIGHT> to select the digit to be altered. a.
Use <UP> or <DOWN> to increase or decrease the number value of that digit. b.
Repeat until the address is set as desired. c.
Press <ENTER>.
5.
Network Setup
The universe of the TCP/IP protocol will be the universe of the DMX function.
Ethernet To DMX
The Maverick MK2 Spot can convert a single ethernet input signal to a single DMX output signal.
To activate or deactivate the Ethernet to DMX function, do the following:
Press <MENU> repeatedly until the Home Screen shows on the display. Press <ENTER>.
1.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Network Setup, or touch the display 2.
where it says Network Setup.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP> or <DOWN> to select Ethernet to DMX, or touch the display where it says Ethernet 4.
to DMX.
If using the buttons instead of the touchscreen, press <ENTER>. 5.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select NO (deactivate) or YES (activate), or 6.
touch the display where it says the desired setting.
Press <ENTER>.
7.
IP Mode
The IP address of the Maverick MK2 Spot can be set manually, by the network, or to a pre-set static
address specific to each product. To set the IP Mode, follow the instructions below:
Press <MENU> repeatedly until the Home Screen shows on the display. Press <ENTER>.
1.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Network Setup, or touch the display 2.
where it says Network Setup.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP> or <DOWN> to select IP Mode, or touch the display where it says IP Mode. 4.
If using the buttons instead of the touchscreen, press <ENTER>. 5.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select from: 6.
• Manual (set the IP address with the control panel),
• DHCP (the network sets the IP address),
or
• Static (a pre-set address specific to each product),
or touch the display where it says the desired mode.
Press <ENTER>.
7.
