Operation
-18- Maverick MK2 Spot User Manual Rev. 4
Test Mode
Auto Test
To perform an auto test of the Maverick MK2 Spot functions, follow the instructions below:
Press <MENU> repeatedly until the Home Screen shows on the display. Press <ENTER>. 1.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Test, or touch the display where it says 2.
Test.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP> or <DOWN> to select Auto test, or touch the display where it says Auto test. 4.
Press <ENTER>.
5.
Manual Test
To test the functions of the product manually, do the following:
Press <MENU> repeatedly until the Home Screen shows on the display. Press <ENTER>. 1.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Test, or touch the display where it says 2.
Test.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP> or <DOWN> to select Manual test, or touch the display where it says Manual test. 4.
If using the buttons instead of the touchscreen, press <ENTER>. 5.
Use <UP> or <DOWN> to select the function to test, from Pan, Pan Fine, Tilt, Tilt Fine, P/S 6.
Speed, Dimmer, Dimmer Fine, Shutter, Virtual Shaking, Cyan, Magenta, Yellow, CTO,
Color, Gobo, Gobo Rotate, Gobo 2, Gobo 2 Rotate, Focus, Focus Fine, Focus Auto, Zoom,
Zoom Fine, Prism, Prism Rotate, Iris, Frost, CMY Macro, CMY Macro Speed, or Special
Function, or touch the display where it says the desired function.
If using the buttons instead of the touchscreen, press <ENTER>. 7.
Change the value of the tested function with one of the following methods: 8.
• Type the desired value using the number pad that shows on the touchscreen display.
or
• Use <UP>, <RIGHT>, <DOWN>, or <LEFT> to increase or decrease the value.
Press <ENTER>.
9.
System Information
All information about the current status of the Maverick MK2 Spot is available through the product’s
Sys Info menu. To view this information, follow the instructions below:
Press <MENU> repeatedly until the Home Screen shows on the display. Press <ENTER>.
1.
Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Information, or touch the display where it 2.
says Information.
If using the buttons instead of the touchscreen, press <ENTER>. 3.
Use <UP> or <DOWN> to select from Fixture Information (shows firmware version, running 4.
mode, starting address, etc.), Fan Information (shows speed of the head fans in rpm), Error
Information (shows any errors or No Error!), or Channel Information (shows the current value
of all signal input channels) or touch the display where it says the desired option.
Press <ENTER>. 5.
Use <UP> or <DOWN> to scroll through the information.
6.
