Maverick MK2 Spot - DMX Parameters - 24 Channel Mode

Operation
-22- Maverick MK2 Spot User Manual Rev. 4
32CH
Channel
Function
Value
Percent/Settings
17
Gobo Wheel 1 Index
Fine
000ó255 0–100%
18
Gobo Wheel 2
[Gobo Designs]
000ó008
009ó017
018ó026
027ó035
036ó044
045ó053
054ó063
064ó073
074ó082
083ó091
092ó100
101ó109
110ó118
119ó127
128ó191
192ó255
Open
Gobo 1 (spiral)
Gobo 2 (dot chiclets)
Gobo 3 (splat breakup)
Gobo 4 (wavy bar)
Gobo 5 (shower glass)
Gobo 6 (lenticular glass)
Gobo 6 Shaking
Gobo 5 Shaking
Gobo 4 Shaking
Gobo 3 Shaking
Gobo 2 Shaking
Gobo 1 Shaking
Open
Clockwise gobo scroll, fast to slow
Counter-clockwise gobo scroll, slow to fast
19 Gobo Rotating 2
000ó063
064ó145
146ó149
150ó231
232ó255
Rotating Gobo Index
Clockwise rotating, fast to slow
Stop
Counter-clockwise rotating, slow to fast
Bounce effect
20
Gobo Wheel 2 Index
Fine
000ó255 0–100%
21
Focus
000ó255
0–100%
22
Fine Focus
000ó255
0–100%
23 Auto Focus
000ó010
011ó030
031ó050
051ó070
071ó090
091ó110
111ó130
131ó150
151ó170
171ó190
191ó210
211ó255
No Function
0-5m
6m
7m
8m
9m
10m
12.5m
15m
17.5m
20-60m
Auto-detect distance
24
Zoom
000ó255
0–100%
25
Fine Zoom
000ó255
0–100%
26 Prism
000ó004
005
ó
255
No Function
Prism Effect
27 Prism Rotate
000ó127
128ó189
190ó193
194ó255
Rotating position
Clockwise rotating, slow to fast
Stop
Counter-clockwise rotating, fast to slow
28 Iris
000ó063
064ó127
128ó191
192ó255
Big to small
Auto change, slow to fast
Slow zoom in, fast zoom out (slow to fast)
Slow zoom out, fast zoom in (slow to fast)
29
Frost
000ó255
0–100%
30 CMY Macro
000ó009
010ó255
No function
CMY macro
31
CMY Macro Speed
000ó255
fast to slow
