-24- Maverick MK2 Spot User Manual Rev. 4
24CH
Channel
Function
Value
Percent/Settings
13 Color Wheel
000ó006
007ó013
014ó020
021ó027
028ó034
035ó041
042ó047
048ó059
060ó187
188ó219
220ó223
224ó255
Open
Red
Orange
Green
Blue
Magenta
Yellow
UV
Split colors
Clockwise color scroll, fast to slow
Stop
Counter-clockwise color scroll, slow to fast
14
Gobo Wheel 1
[Gobo Designs]
000
ó
008
009ó017
018ó026
027ó035
036ó044
045ó053
054ó063
064ó073
074ó082
083ó091
092ó100
101ó109
110ó118
119ó127
128ó191
192ó255
Open
Gobo 1 (circuits)
Gobo 2 (ring of rings)
Gobo 3 (checker vortex)
Gobo 4 (triangle)
Gobo 5 (star field)
Gobo 6 (lenticular glass)
Gobo 6 Shaking
Gobo 5 Shaking
Gobo 4 Shaking
Gobo 3 Shaking
Gobo 2 Shaking
Gobo 1 Shaking
Open
Clockwise gobo scroll, fast to slow
Counter-clockwise gobo scroll, slow to fast
15 Gobo Rotating 1
000
ó
063
064ó145
146ó149
150ó231
232ó255
Rotating Gobo Index
Clockwise rotating, fast to slow
Stop
Counter-clockwise rotating, slow to fast
Bounce effect
16
Gobo Wheel 2
[Gobo Designs]
000ó008
009ó017
018ó026
027ó035
036ó044
045ó053
054ó063
064ó073
074ó082
083ó091
092ó100
101ó109
110ó118
119ó127
128ó191
192ó255
Open
Gobo 1 (spiral)
Gobo 2 (dot chiclets)
Gobo 3 (splat breakup)
Gobo 4 (wavy bar)
Gobo 5 (shower glass)
Gobo 6 (lenticular glass)
Gobo 6 Shaking
Gobo 5 Shaking
Gobo 4 Shaking
Gobo 3 Shaking
Gobo 2 Shaking
Gobo 1 Shaking
Open
Clockwise gobo scroll, fast to slow
Counter-clockwise gobo scroll, slow to fast
17 Gobo Rotating 2
000ó063
064ó145
146ó149
150ó231
232ó255
Rotating Gobo Index
Clockwise rotating, fast to slow
Stop
Counter-clockwise rotating, slow to fast
Bounce effect
18
Focus
000ó255
0–100%
19
Zoom
000ó255
0–100%
20 Prism
000ó004
005ó255
No function
Prism effect
