Max P Series User Manual

P-Series User Manual Rev2022 31
an ISO 9001:2015 certified company
Max Machinery, Inc.
33A Healdsburg Avenue
Healdsburg, CA 95448
maxmachinery.com
T +1 707. 433.2662 ©2008-2022
Positive Displacement Flow Meters
Piston Type, P-Series 250 psi (17 bar) rated
Product includes single directional calibration, bi-directional
calibrations for Analog and Quadrature devices are optional.
Flow Meter Selections Transmitter Selections
Model # LA
/ /
1
-
Non-Standard Options
Bi-Directional Cal: BID
1 Transmitter Type
Max Flow Range Output Type
0.2 Liters/Min P001 A A 4-20mA Output - Powered by 24 Vdc
A B 4-20mA Output - Powered by 12 Vdc
A C 0-10 Volt Output - Powered by 24 Vdc
A D 0-10 Volt Output - Powered by 12 Vdc
P N 5V Pulse/Freq. - Powered by 5-26 Vdc
Q N 5V Quadrature - Powered by 5-26 Vdc
P S Current Sinking, Single Phase
Pressure Temperature Rating
250 psi (17 bar) LA 1 90°C Industrial
Fluid Connection Electrical Connection
1/4” and 6mm Tube 3 1 Industrial, Turck® Connector
Seal Selection Signal Type
Viton® - FKM 1 P Pulse
Per uoroelastomer - FFKM 5 A Analog
Q Quadrature
Options
None NA

Max P Series Specifications

General

Brand	Max
Model	P Series
Category	Measuring Instruments
Language	English
