OI, motor, sensor, and parallel I/O cables
Figure 9 shows the system connection overview for sensor types
SE-47, SE-11, SE-22, SE-44R, and SE-31. Sensor 1 should be
sensing the web on Guide 1. The same is true for the other guides
and sensors.
The controller can control four guides; however, when using the
SE-26A sensor it will only control two guides. See Figure 10 on
next page.
Figure 9. System connection overview for sensors types SE-47, SE-11, SE-22, SE-44R, or SE-31.
