Maxcess FIFE SE-44R User Manual

TECHNICAL DATA 6 - 1
SE-44R / SE-44
Ultrasonic Sensor
www.maxcess.eu MI 1026 1 A
TechnDaten.fm
6 TECHNICAL DATA
General information Dimensions
Gap widths: 51mm
effective gap width at 45° mounting: 19mm
effective gap width at 55° mounting: 28mm
Throat length: 51mm
Weight: 130g
Protection class
IP40
Ambient conditions
Ambient temperature: 0°C - 60°C
Relative humidity: up to 85% non-condensing
Operating altitude max. 5000m above sea level
Materials used
Housing: ABS (acrylonitrile/butadiene/styrene), nickel-plated.
Data sheet can be requested on these material (ABS: EK0143).
Properties Source
Ultrasonic
Frequency
ca. 40kHz
Proportional band
10mm (Sensor field of view)
Linearity
10% max. error (10% .. 90%)
Web plane change
5% max. error (at 45° angle between web and sensor)
Temperature error
7% (at 10°C .. 50°C)
