INSTALLATION3 - 1
SE-44R / SE-44
Ultrasonic Sensor
www.maxcess.euMI 1026 1 A
3 INSTALLATION
Transport and storage – The sensor and/or the unit on which the sensor is mounted
must be secured against slipping during transport.
– The sensor must be stored in a cool, dry place.
– The sensor must not be stored in the vicinity of powerful
magnetic fields. The electronic components of the sensor
may be damaged.
Mounting
WARNING
Ö All assembly tasks on the sensor must be performed when
there is no electrical power in the system.
Ö Assembly tasks and mechanical settings must only be
performed when the machine has been stopped and has been
secured from being turned on again.
Mounting location –Protection Class: IP40
– Operating temperature: 0°C ... 60°C
– Relative humidity: up to 85% non-condensing
– Operating altitude: max. 5000m
– Not in places where there is a risk of explosions.
