MAXDATA PLATINUM 300 IR - System Features

PB 9MAXDATA PLATINUM 300 IR M8Board Features
2 System Features
This chapter briefly describes the main features of the server system.
Table 1 summarizes the major features of the board.
Table 1. Feature Summary
Feature Description
Chassis Dimensions 43.5 mm high
430 mm wide
569 mm deep
17.0 kg max. chassis weight
Processor • Supports Dual-Core Intel
®
Xeon
®
processor 3000 series and Quad-
Core Intel
®
Xeon
®
processor 3200 series
• Supports Intel
®
Extended Memory System 64 Technology (EM64T)
Memory Four DIMM sockets supporting stacked DDR2 667/800 MHz ECC or
non-ECC unbuffered memory (up to 8 GB of total system memory)
Chipset Intel
®
3200 Chipset, consisting of:
• Intel
®
3200/3210 Memory Controller Hub (MCH)
• Intel
®
I/O Controller Hub (ICH9R)
• Intel
®
6702 PXH-V PCI-X Hub
Peripheral Interfaces Super I/O: Winbond 8374LF2
External connections:
• Stacked PS2 ports for keyboard and mouse
• DB9 Serial A port
• Two RJ45 NIC connectors for 10/100/1000 Mbps connections
• Two USB 2.0 ports
Internal connections:
• One USB port header which supports two USB 2.0 ports
• One DH10 Serial B header
• Six SATA connectors (3 Gbit/s) with integrated RAID support
• ATX-compliant 24-pin control panel header
Video On-board iBMC Server Engine with integrated video adapter and
external 32MB video memory
LAN • Intel
®
10/100/1000 82566E Gigabit Ethernet Controller
• Intel
®
10/100/1000 82541PI Gigabit Ethernet Controller
Expansion Capabilities • One x8 PCI Express connector on a full size riser card
Fans Support for two system fans and one processor fan
System Management Intel
®
System Management Software
