24
Display Connections
Description Command Data Options
Closed Captioning CCD OFF, CC1, CC2, CC3, CC4, TX1, TX2, TX3, TX4
Zoom ZOM WID=16:9, PAN=Panorama Stretch, NOR=4:3 with black bars, ZO1=Zoom1,
ZO2=Zoom2
PIP PIP PON=PIP On, OFF=PIP Off
POP POP PON=POP On, OFF=POP Off
PIP Position PIS PS1=Position 1, PS2=Position 2, PS3=Position 3, PS4=Position 4
POP Format POF PF1=Full size, PF2=16:9 Format, PF3=4:3 Format
Sub-Source SIN AV1=AV Input 1, AV2=AV Input 2,
CP1=Component Input 1, CP2=Component Input 2, RG1=RGB1
DV1=DVI1
Sub-Swap SWP 000
R-Gain RGN 001…256
G-Gain GGN 001…256
B-Gain BGN 001…256
R-Bias RBS 001…256
G-Bias GBS 001…256
B-Bias BBS 001…256
Clear Buffer Escape Key Simply press the ESC key on the keyboard will send command to clear command buffer
