9
Table 2-3 Connection LED on the Front Panel
LED
Color
Description
Connection
Green
 Illuminates solid green when the device
is successfully connected via USB cable
but there is no communication with the
vehicle.
 Flashes green when the device is
successfully connected via USB cable
and there is communication with the
vehicle.
Blue
 Illuminates solid blue when the device is
successfully connected via BT but there
is no communication with the vehicle.
 Flashes blue when the device is
successfully connected via BT and there
is communication with the vehicle.
Technical Specifications
Table 2-4 Specifications
Item
Description
Communications
 BT V.2.1 + EDR
 USB 2.0
Wireless Frequency
2.4 GHz
Input Voltage Range
12 VDC
Supply Current
150 mA @ 12 VDC
Operating Temp.
0°C to 50°C (ambient)
Storage Temp.
-20°C to 70°C (ambient)
Dimensions
(L x W x H)
87.0 mm (3.43”) x 52.0 mm (2.05”) x24.5
mm (0.96”)
Weight
76 g (0.168 lb.)
