3.1 Parts List
ITEM
QTY
GNE P/N
DESCRIPTION
1
1
80002
BOLT, CARR, 1/4-20 X 3/4, GR5, ZINC
5
2
400186
5/16-18 X 1 HEX SCREW GR 5 - ZINC
6
4
80039
5/16-18 X 1-3/4 HEX SCREW GR 5-
7
4
400265
3/8-16 X 1-1/2 HEX SCREW GR 5-ZINC
8
1
400267
BOLT, HHCS, 3/8-16 X 2, GR5, ZINC
9
1
400238
1/2-13 X 1-1/4 HEX SCREW GR 5-ZINC
10
12
80205
5/16 SAE FLAT WASHER - ZINC
11
21
80206
WASHER, SAE, 3/8, ZINC
12
1
85128
1/4" NYLON LOCK NUT
13
4
86101
5/16 NYLON LOCK NUT
14
2
86315
SET SCREW, 1/4-20 X 1/4
15
9
86383
NUT, NYLOCK, 3/8-16, GR5, ZINC
16
3
86454
KEY-SQUARE 3/16 X 1
17
1
86740
1/4-20 NUT, NYLON INSERT
18
1
87268
5/16-18 X 5/16 SETSCREW ZN
19
1
400256
BOLT, HHCS, 5/8-18 X 9, GR5, ZINC
20
3
87373
NUT, CLIP, 1/4-20, 0025-015, BLACK
21
1
359301
CHAIN, #40, 80 LINKS
22
2
140101
BEARING, PILLOW BLOCK, 3/4"
24
1
87451
KIT, HARDWARE, PH
24.1
5
400186
5/16-18 X 1 HEX SCREW GR 5 - ZINC
24.2
6
86101
5/16 NYLON LOCK NUT
24.3
1
359360
S-HOOK
24.5
1
790471
HOLDER, MANUAL, SMALL
24.7
2
87568
ASSY, CABLE, CLUTCH
24.8
1
87383
OWNERS MANUAL, PH50B
24.9
1
80214
WASHER, 5/16, USS, ZINC
24.10
1
80212
1/4 USS FLAT WASHER - ZINC
24.11
1
87374
P-CLIP, 3/8 X 9/16, GAL
24.12
1
87416
SPRING, EXTENSION (MS,GM,MT)
24.13
1
86115
5/16-18x1-1/4 HEX SCREW GR 5-ZINC
25
1
87557
KIT, DECAL, SHEET, PH50B
28
1
87633
SPROCKET, 40B12, 3/4 BORE
29
1
87634
SHAFT, .75 DIA, KEYED, FULL, ZINC
34
1
130600
HANDLE ASSEMBLY -PAINT (PH50B)
34.1
1
336683-PH
CLUTCH LEVER - PAINT (MS)
34.2
1
87372
POST, BINDING, 0.25 X 1.25, ZINC
34.3
1
87425
BOLT, TRUSS, #10-24 X 5/16, ZINC
34.4
2
313786
HANDLE GRIP, 1
34.6
1
130600-SD
WELDMENT, HANDLEBAR, PH50
35
2
130604
HANDLE BRACE - PUNCH (PH50B)
36
1
132107
ASSY, ENGINE, PH
36.10
1
132106
ENGINE 127CC BRIGGS 550 HORIZ. 6:1
36.11
1
336669
MOTOR PULLEY PH50B
36.12
2
87268
5/16-18 X 5/16 SETSCREW ZN
36.7
2
80212
1/4 USS FLAT WASHER - ZINC
36.9
1
500073
WLD, GUIDE, BELT, PH
37
1
162003
KICKSTAND - PAINT (PH50B)
39
1
162030
ARM, IDLER CLUTCH (PH50B)
40.1
1
162002
HUB, REAR WHEEL (PH50B)
40.2
1
131110
SPROCKET, #40A50
40.3
1
162001
WHEEL, ASSEMBLY
40.4
2
140110
ROLLER BEARING REAR
40.5
4
400186
5/16-18 X 1 HEX SCREW GR 5 - ZINC
40.6
4
87463
NUT, NYLOCK, FLG, 5/16-18, GRF, ZP
40.7
4
400238
1/2-13 X 1-1/4 HEX SCREW GR 5-ZINC
40.8
4
87465
NUT, NYLOCK, JAM, 1/2-13, GF, ZP
41
1
272212
BELT, AP62
42
1
336666
PULLEY, 10" X 3/4" (PH50B)
44
1
336690
SHANK, PLOW FOOT - PAINT
45
1
336691
R.H. PLOW FOOT - PAINT
46
1
336692
L.H. PLOW FOOT - PAINT
47
1
336693
SWEEP, 12"
48
1
336696
10" FURROWER
49
1
336697
7" TURN SHOVEL, R.H.
50
1
359321
IDLER PULLEY, 2-1/4" X 3/8"
51
2
446155
SERRATED RETAINER
52
1
162000
WLD, FRAME, PH50B
53.1
1
130602
BAR, SIDE ADJUSTMENT (PARTS)
53.2
1
130709
WHEEL, 8" X 1.50" <REG> (M30B)
53.3
1
87314
1//2-13 x 1 1/4 HHCS GR5 ZP
53.4
1
86383
NUT, NYLOCK, 3/8-16, GR5, ZINC
53.5
1
359330
WHEEL SHOULDER BOLT 2 5/16"
53.6
2
80206
WASHER, SAE, 3/8, ZINC
53.7
1
130601
DEPTH ADJUSTER BRACKET
54
1
500049-
87557
ASSY, GUARD, BELT, PLOW HOSS
55
1
500051
MNT, BELT GUARD, REAR, PH
57
1
443815
NUT, NYLOCK,5/8-18, JAM, G5, Z
58
3
400110
BOLT, HEX, 1/4-20 X 3/4, GR5, ZINC
59
1
80034
BOLT, HEX, 1/4-20 X 2-1/4, GR5, ZP
60
3
87648
BOLT, HH 3/8-16 X 2 1/2 GR5 ZP
61
1
162046
THROTTLE CONTROL
62
1
87669
WASHER, WAVE, 3/8", STL
63
1
87325
7/16 -14 X 2 PLOW BOLT
64
1
80216
WASHER, USS, 7/16, ZINC
65
1
86422
NUT, NYLOCK, 7/16-14, ZINC
66
1
500074
SPACER PH50B
67
1
87690
BOLT, HEX, 3/8-16, 3-1/4", GR5, ZC
