7.3 Plow Height Adjustment and Front Wheel Adjustment
Plow height is adjusted by inserting the Vertical Wheel adjustment into the Frame pipe mount at
desired height and tightening the lock bolt.
A secondary height adjustment would be at the front wheel side adjustment, by rotating the
wheel mounting frame. The front wheel can be mounted on either side, depending on the type of
plowing to be done, use the side adjustment that best suits your plowing, then tighten the locking
bolt.
8 Maintenance
⚠ DANGER: To avoid possible serious bodily injury, when performing any adjustments, remove
the spark plug wire and place the wire away from the plug to prevent accidental starting.
8.1 Periodic Check
1. Regularly check all bolts and nuts for tightness.
2. If the belt begins to bottom out on the engine pulley, then replacement of the pulley is
needed. This is noticeable by the pulley “V” bottom becoming shiny.
8.2 Engine Oil
1. Check the oil level before starting the engine and after every five hours of operation.
2. Be sure engine is cool.
3. Before removing the filler plug, clean the area around it to prevent dirt from entering the
oil fill hole.
4. The engine should be in a level position when checking the oil.
5. Remove the filler plug and fill the crankcase with oil.
DANGER
To avoid possible serious bodily injury, when performing any adjustments, remove the
spark plug wire and place the wire away from the plug to prevent accidental starting.
Vertical wheel adjustment
