Maxima 2 - Page 35

Chapter 6
Washing
35
Always wear suitable protective gloves.
Note: Regularly check the integrity of the gaskets and substitute them if they are broken, worn or swol-
len.
Only use original gaskets, made of food-safe rubber. The gaskets and their seats must be carefully
lubricated before re-use. A full spare set of all gaskets is supplied with the machine, plus a tube
of food-safe grease for lubricating them.
3. Rinsing phase to remove detergent:
After washing with detergent, all the parts must be thoroughly rinsed.
- Use room temperature drinking water to rinse all components previ-
ously removed and washed separately.
c) Refitting the components:
After washing, re-fit all of the machine components as described below:
• Reassembling the outlet nozzle, splash guards and cream distributor
- Position the gasket (16) on the cream distributor (14).
- Screw the cream distributor (14) onto the dispensing tap (8) by turning
it in a clockwise direction using the labyrinth fixing rod (10).
- Then screw the outlet nozzle (13) onto the cream distributor (14) by
turning it in a clockwise direction.
• Reassembling the dispensing tap, labyrinth tube and labyrinth
- Position the gaskets (12) in the housings on the labyrinth (11).
14
16
14
10
8
13
14
13
12
11
11
