11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
10
PERIODIC MAINTENANCE CHECKS
Never operate the Liftgate if parts are loose or missing.
WARNING
NOTE: Make sure vehicle is parked on level ground while performing the maintenance
checks.
Quarterly or 1250 Cycles (whichever occurs fi
rst)
Semi-annually or 2500 Cycles (whichever occurs fi rst)
Visually check the platform hinge pins for excessive wear and broken welds. See PARTS
BREAKDOWN section for replacement parts. Also, do the Quarterly or 1250 Cycles
maintenance checks.
Check the hydraulic ! uid level in the pump reservoir. Refer to the CHECKING HYDRAULIC
FLUID procedure in the PERIODIC MAINTENANCE section.
If hydraulic ! uid appears contaminated, refer to the CHANGING HYDRAULIC FLUID
procedure in the PERIODIC MAINTENANCE section.
Keep track of the grade of hydraulic ! uid in the pump reservoir and never mix two different
grades of ! uid.
Check all hoses and " ttings for cha" ng and ! uid leaks. Tighten loose " ttings or replace
parts as required.
Check electrical wiring for cha" ng and make sure wiring connections are tight and free of
corrosion. Use dielectric grease to protect electrical connections.
Check that all WARNING and instruction decals are in place. Also, make sure decals are
legible, clean and undamaged.
Check that all bolts, nuts, and roll pins are in place. Make sure roll pins protrude evenly
from both sides of hinge pin collar. Replace fasteners and roll pins if necessary.
PERIODIC MAINTENANCE
!
Check for rust and oily surfaces on Liftgate. If there is rust or oil on Liftgate, clean it of
f.
Touch up the paint where bare metal is showing. MAXON recommends using the aluminum
primer touchup paint kit, P/N 908134-01.
Damaged cylinder seals and contaminated hydraulic fl uid can result from painting
the polished portion of the cylinder rod. T
o prevent damage, protect the exposed
polished portion of the cylinder rod while painting.
CAUTION
Check for debris and dirt buildup on the slider rollers and rails. Clean out any buildup of dirt
and debris.
